| 產品參數 | |||
|---|---|---|---|
| 品牌 | 紐比特 | ||
| 加工定制 | 是 | ||
| Model No. | LASER638CPD | ||
| Wavelength | 638 /-6 nm | ||
| Spatial Mode | Multi mode | ||
| Output Power | 1000mW | ||
| Operation Mode | CW or Modulation | ||
| Beam Height | 25mm | ||
| Beam Size | 3x5mm | ||
| Beam Divergence(full angle) | 1.5mrad | ||
| Power Stability | <3 per 4 hrs | ||
| Warm Up Time | <1 minute | ||
| MTTF | 10 | ||
| 000 hrs | |||
| Laser head dimensions | 102(L)x40(W)x42(H)mm3 | ||
| Power Supply | Lab Adjustable type 179 mm (W)x148 mm (D)x56 mm (H) 220V 50/60Hz b | ||
| Modulation | 0~30khz Analog or TTL | ||
| 可售賣地 | 全國 | ||
| 型號 | LASER | ||
FEATURES
Longlife operationAnalog/TTL modulationCollimated straight beamHigh efficiencyHigh reliability
APPLICATIONS
Laser showDisplayLaser AlignmentScanning BiochemistryMaterial Inspection Lidar
Laser Head Drawing
power supply
