Sensor model |
On Semi Lupa 3000 |
|
Resolution max. |
1.696 (H) x 1.710 (V) |
|
Framerate with full resolution |
540 fps |
|
CXP connector |
BNC |
|
Exposure time |
2 μs - 1/framerate |
|
Active area |
13.57 x 13.68 mm |
|
Pixel size |
8 μm square |
|
A/D converter |
8 bit |
|
SNR |
43 dB (EMVA 1288) |
|
Dynamic range |
55 dB (EMVA 1288) |
|
Sensitivity |
3.8 V/lux*s @ 525 nm |
|
Trigger modes |
internal free-run, external, CXP |
|
External trigger |
TTL signal, 3.3-5V, 10mA, optically isolated |
|
Lens mount |
F-mount, C-mount, M42-mount, custom, all exchangeable |
|
Power |
PoCXP (Power over CoaXPress, 12 W) |
|
Dimensions (W x H) |
85 mm x 85 mm |
|
Conbity |
CE, RoHS, GenICam |
|
Scope of delivery |
Camera, manual, synchronisation cable |
